Front Loading Dishwashers - UD503D

Name: Front Loading Dishwashers - UD503D
Brand: Smeg
SKU: UD503D

SKU·UD503D

053 861 4301

2-year warranty

Parts & labour

Nationwide

Delivery

In-house

Repairs & spares

Key specifications

From catalog

Boiler Capacity: 6 l
Tank Capacity: 16 l
Power Connection: 400 V 3N~ / 12 A / 5,7 kW / 50 Hz
Basket Dimensions: 500x500 mm
Packed Product Dimensions: 990X660X700
Product Dimensions Wxdxh: 578x600x814 mm
Gross Weight (Kg): 60.000
Tank Material: Stainless steel AISI 304

Show all specifications (63 more)

Max Temperature Inlet Water: 60°C
Adjustable Feet: Yes
Automatic Start: Yes, default OFF
Back Panel: Galvanized
Boiler Heating Element: 4960 W
Construction: Single wall
Cycle Counter: Yes
Default Connection: 5650 W
Depth Packed Product: 700 mm
Depth With Open Door: 1000 mm
Detergent (Red) Hose Lenght: 2,2m
Detergent Load: 1,5 l/h
Display: 4 digit
Door: Double wall
Door Gasket: Only up
Drain And Self Cleaning Cycle: Yes
Drain Pump: Yes
Family: Professional dishwasher
Filter: 4-stages filter system
Functionality: GN 1/1 trays washing, 5-stage filter, Door clearance 365mm
Height Packed Product: 990 mm
Inlet Pressure: 2,5-6 bar / 250-600 kPa
Led Color: Red
Manual Diagnostic: Yes
Max Water Hardness: 12°f - 7°dH
Maximum Basket/Hour: 40
Maximum Dishes/Hour: 720
Noise: Lpa 55,5 dBA
Number Of Buttons: 5
On/Off Button: Yes
Optional Electrical Connection: 230 V 3~ / 16 A / 5,7 kW / 50 Hz; 220 V~ / 12 A / 2,7 kW / 50 Hz; 220 V~ / 14 A / 3,1 kW / 50 Hz; 220 V~ / 18 A / 4.0 kW / 50 Hz
Packaging Type: Carton on pallet
Panel: Ecoline
Paper Packaging: 3.031 kg
Peristaltic Detergent Doser: Electronic control
Peristaltic Rinse-Aid Doser: Electronic control
Plastic Packaging: 0.100 kg
Polystyrene Packaging: 0.667 kg
Program Options: Extra rinse; Clean water cycle
Program Specifications: Boiler 85°C/Tank 60°C - 1'30"; Boiler 85°C/Tank 60°C - 2'30"; Boiler 85°C/Tank 60°C - 4'
Programs: 3 automatic programs; Self-cleaning programs
Protection Class: IPX4
Rack Guides: Embossed
Rinse Aid (Blue) Hose Lenght: 2,2m
Rinse Load: 0,4 l/h
Rinse Spray Arm: Plastic
Series: Ecoline
Soft Start System: Yes
Solutions: Hotels; Restaurants/Pubs; QSR
Stand-By System: Yes
Subfamily: Undercounter Dishwasher
Tank: With printed base
Tank Filter: Plastic
Tank Heating Element: 2000 W
Thermostop System: Yes
Trays Washing Option: GN1/1 530X32 5mm
Usable Load Height: 340 mm
Warm Water Connection: 8°C
Washing Pump: 680 W
Washing Spray Arm: 2 in stainless steel
Water Cycle Consumption: 3,2 l
Width Packed Product: 660 mm
Wood Packaging: 5.000 kg

Description

[caption id="attachment_18623" align="alignnone" width="121"]

Download Spec sheet[/caption]

TARGET

Solutions:Hotels; Restaurants/Pubs; QSR

TYPE

Family:Professional dishwasher

Subfamily:Undercounter Dishwasher

Basket dimensions:500x500 mm

Panel:Ecoline

Power connection:400 V 3N~ / 12 A / 5,7 kW / 50 Hz

Usable load height:340 mm

Depth with open door:1000 mm

Product dimensions WxDxH:578x600x814 mm

AESTHETICS

Series:Ecoline

Led color:Red

FUNCTIONS

Functionality:GN 1/1 trays washing, 5-stage filter, Door clearance 365mm

PROGRAMS

Programs:3 automatic programs; Self-cleaning programs

Program options:Extra rinse; Clean water cycle

Program specifications:Boiler 85°C/Tank 60°C - 1'30"; Boiler 85°C/Tank 60°C - 2'30"; Boiler 85°C/Tank 60°C - 4'

Drain and self cleaning cycle:Yes

Maximum basket/hour:40

Maximum dishes/hour:720

TECHNICAL FEATURES

Tank heating element:2000 W

Boiler heating element:4960 W

Washing pump:680 W

Default connection:5650 W

Water cycle consumption:3,2 l

Inlet pressure:2,5-6 bar / 250-600 kPa

Warm water connection:8°C

Max temperature inlet water:60°C

Max water hardness:12°f - 7°dH

ELECTRICAL CONNECTION

Optional electrical connection:230 V 3~ / 16 A / 5,7 kW / 50 Hz; 220 V~ / 12 A / 2,7 kW / 50 Hz; 220 V~ / 14 A / 3,1 kW / 50 Hz; 220 V~ / 18 A / 4.0 kW / 50 Hz
