TARGET
Suggested for:Bakery
Solutions:Coffee shops/Wine bars; Hotels; Restaurants/Pubs; Bakery/Pastry making; Frozen bakery industry; Food retail; QSR
TYPE
Family:Professional ovens
Subfamily:Convection oven 4 trays EN 600x400 mm or GN1/1
Oven type:Multifunction convection oven with humidiifer
Oven control:Manual
Trays capacity:4 trays EN 600x400 mm or GN1/1 (excluding flat grids and trays)
Power supply:400 V 3N~ / 10 A / 6,9 kW / 50 Hz
Other electrical connection:230 V~ / 30 A / 6.9 kW / 50 Hz
Program storage with application:Not available
Maximum depth with open door:1145 mm
Adjustable feet:Yes
Product dimensions WxDxH:798x747x563 mm
AESTHETICS
Colour:Stainless steel
Door with stainless steel stripes:Yes
Front panel:Yes
PROGRAMME / FUNCTIONS
Backing functions
Convection
Convection with humidification
Up & base
Fan assisted base
Large grill
CONTROLS
Timer setting range:1-60 minutes + endless
OPTIONS
Combinable hood:K4610X
CONSTRUCTION
Oven materials:Stainless steel / glass / plastics
Cavity dimensions (wxdxh):672x437x340 mm
Internal net volume:75 lt
Cavity material:Stainless steel
Shelves number:4
Tray frame support:Chromed wire
Shelves distance:77 mm
Door construction:Double glass
Door opening:Tilting
Glass:With clip
Fan type and number:2 contrarotating with timed direction reversal
Fan motor power:Progressive %
Engine rpm:Single speed
Humidification levels:Manual
Exhaust position:Back
Timer type:Electric
Temperature range:70-270°C
Safety switch with open door:Yes
IPX protection:IPX3
LOGISTIC INFORMATION
Gross volume:115,6 lt
Packed width:950 mm
Net volume:104,2 lt
Packaged depth:840 mm
Handle type:Fixed
Height (mm) packed:640 mm
End cooking signal:Yes
Orange light indicator t° achievement:Yes
Green light indicator time achievement:Yes
Manual reset safety thermostat:Yes
Removable deflector:Yes
Lighting:2 LED lamps
